Fit the ergonomics, fingertip type operation.
Compact design, abve the panel install,convenience installation;
can be installed side by side, save installation space as far a possible.
Contactless hall technology, high reliability , long life.
Specially designed for severe environment, the electronic parts protection grade:IP67
Industrial remote control, Control panel, Manipulation of the armrest box
S= spring return
F= spring return, +-23 degree end resistance(feel point)
L= spring return, postition locking(latch)
H11= Hall type, power voltage 5Vdc, 0.5~4.5v voltage output
H12= Hall type, power voltage 5Vdc, 0~5v voltage output
W11= Hall type, power voltage 9~32Vdc, 0.5~4.5v voltage output
W12= Hall type, power voltage 9~32Vdc, 0~5v voltage output
Handle top color mark:
